Used Komatsu PC360 Crawler Excavator 36 Ton Heavy Duty Digger for Sale

Name: Used Komatsu PC360 Crawler Excavator 36 Ton Heavy Duty Digger for Sale - Taihongmachinery
Price: 34000.00 USD
Availability: InStock

1-2 Unit$35,000

>=3 Units$34,000

（Price is FOB . Contact WhatsApp for CIF price & shipping cost.）

Used excavator Volvo excavator comparison. Crawler excavator used Komatsu PC360, 36 ton heavy duty digger for sale. High efficiency, low operating costs

Brand	Komatsu
Model Number	PC360
Country of Origin	Japan
Year	2024
Working Hours	500H

Categories: Excavator, Komatsu

Tags: Construction Machinery, crawler excavator, Komatsu PC360

Inquire now

Product Categories

Laney

Business Manager

Call

Inquire now

Product Specifications

No	Item	Data
1	Type	Komatsu PC360-8
2	Operating weight	33550kg
3	Bucket capacity	1.6-1.9m³
4	Boom length	6470mm
5	Stick length	3185mm
6	Rotation speed	9.5rpm
7	Walking speed	3.2-5.5km/h
8	Gradeability	35°/70°
9	Bucket digging force	227KN
10	Stick digging force	171KN
11	Engine model	Komatsu SAA6D114E-3
12	Rated power	187kw/1950rpm
13	Hydraulic pump	Komatsu
14	Distribution valve	Komatsu
15	Displacement	8.27L
16	No. of cylinders	6
17	Cooling method	water-cooling
18	Fuel tank	605L
19	Length	11140mm
20	Width	3190mm
21	Height	3285mm
22	Maximum excavation radius	11100mm
23	Maximum excavation depth	7380mm
24	Maximum excavation height	10100mm
25	Maximum unloading height	7050mm
26	Maximum vertical excavation depth	6400mm

Product Pictures

Expert Inspection Report

The Komatsu PC360 is a powerhouse in the 36-ton excavator category, engineered for high-production environments where machine uptime and structural strength are critical. At Taihongmachinery, our technical assessment marks the PC360 as one of the most reliable investments for heavy-duty earthmoving, quarrying, and large-scale infrastructure projects.

1. High-Torque Performance & Engine Reliability

Equipped with the high-displacement Komatsu SAA6D114E engine, the PC360 delivers exceptional digging force even at low engine speeds. Its advanced fuel injection system is designed for high efficiency, allowing it to handle sustained heavy loads with ease. For our clients in Africa and Southeast Asia, this engine’s proven reliability under varying fuel conditions is a major strategic advantage.

2. Superior Stability for Heavy Lifting

The PC360 features a wider and more robust undercarriage compared to standard 30-ton models, providing a highly stable platform for heavy lifting and deep excavation. This enhanced footprint ensures that the machine remains balanced even when working on uneven or soft terrain, reducing stress on the swing circle and upper structure during full-bucket operations.

3. Precision Hydraulics: The HydrauMind System

Utilizing Komatsu’s patented HydrauMind (Hydraulic Mechanical Intelligence New Design) system, the PC360 offers a closed-center load-sensing experience that is both intuitive and powerful. The system matches hydraulic flow to the current load, allowing for smooth, simultaneous movements of the boom, arm, and bucket. This precision shortens cycle times and reduces operator fatigue during long shifts.

4. Built to Last: Reinforced Boom and Arm

The structural integrity of a pre-owned PC360 is one of its strongest selling points. The boom and arm are built with thick, high-tensile strength steel and feature large cross-sections to resist torsional stress. At TH Engineering Equipment Limited, we’ve observed that PC360 units maintain their mechanical precision far longer than competitors, ensuring a high resale value in the global market.

5. Why Choose the PC360 from TH Engineering?

At Taihongmachinery, every used Komatsu PC360 goes through a comprehensive 100-point inspection. We focus on the health of the main pump, final drive performance, and engine compression. We provide our international buyers with detailed diagnostic reports and cold-start videos, ensuring that every machine is “job-site ready” the moment it arrives at your port.

Our Verdict: The Komatsu PC360 is a heavy-duty workhorse that doesn’t compromise on efficiency. If your project demands raw power and long-term durability, the PC360 is the most dependable asset for your fleet.

Company Description

Taihongmachinery (TH Engineering Equipment Limited) is a premier global supplier specializing in the export of high-quality, pre-owned heavy construction equipment.
Our company sells Caterpillar,Komatsu,Sany,Doosan,Hyundai,Hitachi,Volvo,Kubota used excavators, used bulldozers, used loaders, used graders, used cranes, used rollers, etc. With a strategic focus on the international trade of used excavators, we have established ourselves as a cornerstone of reliability for clients across Southeast Asia, South Asia, the Middle East, Africa, and South America.

Shipping & Delivery Policy

At Taihong Machinery, we provide flexible global logistics solutions for all our used heavy machinery.

Shipping Method: We recommend working with professional international freight forwarders specializing in heavy equipment (RORO or Flat Rack container shipping).

Flexibility: We are happy to work with your preferred freight forwarder. If you do not have one, we can leverage our network of reliable, certified global logistics partners to provide competitive shipping quotes to your nearest port.

Preparation: All machines undergo professional cleaning and safety inspections prior to loading to ensure they meet international shipping regulations.

Documentation: We provide all necessary export documentation, including Bills of Lading, Packing Lists, and Commercial Invoices, to ensure smooth customs clearance at the destination.

Return & Refund Policy

We provide a detailed pre-shipment inspection report and live video call to confirm machine condition. Returns are generally not accepted, but if the machine does not match the inspection report, we will negotiate a resolution.

Inspection: We encourage all buyers to conduct a thorough inspection of the machine, either in person at our yard in China or via live video consultation with our technicians.

Pre-shipment Verification: Before the machine leaves our yard, we provide a full functional test report and live video proof of the engine, hydraulic, and structural condition. Once the buyer confirms the machine status and the machine is loaded for export, we do not accept returns.

Warranty: All equipment is sold in “as-is” condition. We are committed to transparency and will disclose all known technical details prior to purchase.

Support: Should any issues arise during the shipping process, we will provide full support in communicating with your insurance provider and the shipping line.

Success Cases

The Komatsu PC360 is a 36-ton class hydraulic excavator available in multiple variants, including the latest PC360-11 (LC/NLC) series and the previous PC360-10 generation. Below are the detailed specifications verified by official Komatsu data .

Complete Specifications Table (PC360LC/NLC-11 – Current Model):

Parameter	Value
Model	PC360LC-11 / PC360NLC-11 / PC360LCi-11
Operating Weight	35,800 – 36,900 kg (78,645 – 81,400 lbs)
Engine Model	Komatsu EU Stage V (or Tier 4 Final)
Engine Type	6-cylinder, water-cooled, turbocharged diesel
Rated Power	202 kW (271 HP) at 1,950 rpm
Bucket Capacity	Up to 2.66 m³ (3.5 yd³)
Max Digging Depth	8.18 m (26.8 ft)
Max Digging Height	12.9 m (42.5 ft) on demolition variant

PC360LC-10 (Previous Generation) Specifications:

Parameter	Value
Operating Weight	34,300 – 35,400 kg
Engine Power	202 kW (271 HP)
Bucket Capacity	2.66 m³
Digging Depth	8.18 m
Fuel Consumption	Up to 13% lower than previous models

Hydraulic System Features:

CLSS (Closed Load Sensing System) hydraulics for precise control and fast response
Lift Mode – Increases lifting force by up to 6% with operator selection
Auxiliary Hydraulic Flow – 200-250 L/min (53-66 GPM) for attachments

Transport Dimensions:

Transport Length: Approx. 11,150 mm (36.6 ft)
Transport Width: 3,190 mm (10.5 ft) – NLC variant has narrower undercarriage for transport

The PC360 is available in multiple configurations: LC (Long Crawler) for stability, NLC (Narrow Long Crawler) for transport convenience, and iMC 2.0 variants with intelligent Machine Control technology .

The Komatsu PC360 offers excellent fuel efficiency for its class. The latest -11 series achieves up to 5% lower fuel consumption compared to previous models, while the -10 series delivered up to 13% reduction over earlier generations .

Fuel Consumption Estimates (Based on industry data):

Operating Condition	Approx. Fuel Consumption
Standard digging/loading	18-22 L/hour (4.8-5.8 gal/hour)
Heavy excavation/rock	22-26 L/hour (5.8-6.9 gal/hour)
Light work / grading	14-18 L/hour (3.7-4.8 gal/hour)
Idling	3-5 L/hour (0.8-1.3 gal/hour)

Fuel Efficiency Features on PC360-11:

Komatsu EU Stage V Engine – Advanced electronic control system manages airflow rate, fuel injection, and combustion parameters for optimal efficiency
Auto Idle Shutdown – Automatically shuts down engine after preset idle time, eliminating unnecessary fuel waste
Neutral Detection System – Reduces engine RPM when controls are in neutral for more than 4 seconds
KOMTRAX Fuel Management – Real-time fuel consumption monitoring and reporting via telematics

Fuel Saving Tips for PC360 Operators:

Tip	Estimated Savings
Reduce idle time (avoid unnecessary idling)	10-15%
Use appropriate work mode for application	5-10%
Maintain proper track tension	3-5%
Keep air filters clean	3-5%
Use Lift Mode only when needed (not continuously)	2-3%

Fuel Tank Capacity: The PC360 has a large fuel tank (approximately 605 L / 160 gal), allowing for 27-35 hours of continuous operation between refueling stops, depending on workload intensity.

Cost Calculation Example (at $1.00/L diesel, 2,000 hours/year):

Annual fuel consumption: 40,000 – 52,000 L
Annual fuel cost: $40,000 – $52,000
With 5% fuel savings from efficient operation: $2,000 – $2,600 saved annually

The Komatsu PC360 features a powerful hydraulic system that supports a wide range of heavy-duty attachments, making it highly versatile for construction, demolition, quarrying, and waste management applications.

Hydraulic System Capabilities:

Auxiliary flow: 200-250 L/min (53-66 GPM)
System pressure: 23-26 psi (160-180 kg/m²) standard
Up to 15 programmable flow and pressure settings for different tools

Compatible Attachments and Specifications:

Attachment Type	Model Example	Key Specifications	Applications
Hydraulic Breaker	HBH1500T	Weight: 2,600 kg, Chisel: 150mm, Impact Energy: 6,000 Joules, Rate: 300-450 BPM	Rock breaking, concrete demolition
Rotating Grapple	RHG400	Weight: 2,000 kg, Max Opening: 2,500 mm (98.4″)	Material handling, scrap sorting, demolition
General Bucket	Standard	Capacity: up to 2.66 m³	Earthmoving, trenching, loading
Tilt Bucket	iMC 2.0 compatible	With IMU sensor for angle control	Slope grading, ditch work
Demolition Package	PC360LC-11 Demolition	Straight boom, 12.9m digging height	High-reach demolition

PC360LC-11 Demolition Excavator Features :

Factory-made straight boom for added reach (maximum digging height: 12.9 m / 42.5 ft)
Heavy-duty wraparound side protection and undercovers
Proportional joystick controls for precise attachment movement
Programmable settings for up to 15 different tools

Waste Management Package (PC360LC-11 WH) Features :

Auto reversing fan to minimize debris damage
Engine pre-cleaner for extended air filter life
Wide core cooling package to reduce debris accumulation
Chassis seal package to protect vital components
9-mm thick severe duty revolving frame under covers

Attachment Selection Guide:

Application	Recommended Attachment	Key Consideration
Mass excavation	2.2-2.66 m³ bucket	Maximize payload per cycle
Rock breaking	Hydraulic breaker (2,500-3,000 kg class)	Match weight to machine capacity
Demolition	Demolition package + breaker	Requires reinforced guarding
Material handling	Rotating grapple (2,000 kg)	360° rotation for precision
Scrap yard	Waste package + grapple	Extra guarding and filtration
Grading/sloping	iMC 2.0 + tilt bucket	Auto tilt control for precision

Important: Always verify attachment weight and hydraulic flow requirements with the machine’s specifications. The PC360 supports up to 15 programmable flow/pressure settings, allowing quick switching between multiple attachments .

Following the manufacturer’s recommended maintenance schedule is critical for maximizing the PC360’s service life and minimizing downtime. Below is the comprehensive maintenance schedule based on Komatsu’s official guidelines .

Daily Maintenance (Every 8-10 hours / Before Start):

Component	Maintenance Action
Walk-around Inspection	Check for leaks, damage, loose bolts
Engine Oil Level	Check dipstick, maintain proper level
Hydraulic Oil Level	Check sight glass or tank gauge
Coolant Level	Check radiator and overflow tank
Fuel Level	Check and refill as needed
DEF Tank (Stage IV/V)	Check fluid level
Track Tension	Inspect for proper sag (15-20mm)
Windows and Mirrors	Clean for visibility
Lights and Alarms	Test horn, backup alarm, work lights

Every 50 Hours (Weekly):

Component	Maintenance Action
Air Filter	Check restriction indicator, clean pre-cleaner
Greasing	Lubricate all pivot points (boom, arm, bucket linkage)
Radiator & Oil Coolers	Check for debris blockage, clean fins
Battery Compartment	Check terminals, wiring condition, cleanliness

Every 250 Hours:

Component	Maintenance Action
Swing Gear	Check oil level, inspect for leaks
Fan Belt	Check tension and condition
Fuel Filters	Replace primary and secondary filters

Every 500 Hours :

Component	Maintenance Action
Engine Oil & Filter	Replace with Komatsu approved oil
Hydraulic Filter	Replace element
Fuel Tank	Drain water and sediment
Track Rollers & Idlers	Inspect for wear and damage
Boom & Arm Pins	Inspect for excessive wear

Every 1,000 Hours :

Component	Maintenance Action
Hydraulic Oil	Sample and analyze; replace if contaminated
Swing Machinery Oil	Change (requires 500-hour list)
Engine Valve Clearance	Check and adjust
Fuel Injectors	Inspect and clean/replace as needed

Every 2,000 Hours :

Component	Maintenance Action
Complete Hydraulic Oil Change	Drain, flush, and refill system
Coolant	Replace with fresh coolant
All Filters	Replace all filters (fuel, hydraulic, air, pilot)
Track Adjusters	Inspect and service recoil assemblies

Every 5,000 Hours :

Component	Maintenance Action
Major Engine Service	Full engine inspection and tune-up
Hydraulic Pump	Inspection and reseal if needed
Swing Bearing	Inspection and grease replacement
Complete Undercarriage	Full inspection and component replacement as needed

Undercarriage Inspection Checklist :

Component	What to Check
Tracks	Tension, excessive wear, damage, missing shoes, nuts/bolts
Rollers	Missing rollers, wear, damage
Final Drives	Leaks, unusual noise
Sprockets	Wear pattern, missing teeth

Key Maintenance Tips:

The PC360iMC-11 features an intelligent diagnostic system on the LCD monitor
Use KOMTRAX telematics to track maintenance intervals and receive alerts
The auto reversing fan on waste/demo packages helps keep cooling package clean
Always use genuine Komatsu filters and fluids for warranty compliance

Komatsu offers multiple variants of the PC360 platform, each designed for specific applications, emission standards, and technological capabilities. Understanding these differences helps buyers select the right machine for their needs.

Model Comparison Table:

Feature	PC360-10	PC360-11 / NLC-11	PC360LCi-11 (iMC 2.0)
Introduction	~2011-2020	2015+ (Intermat 2015)	2021+ (iMC 2.0)
Emission Standard	Tier 4 Interim / Stage IIIB	Stage V / Tier 4 Final	Stage V
Engine Power	202 kW (271 HP)	202 kW (271 HP)	202 kW (271 HP)
Operating Weight	34,300-35,400 kg	35,800-36,900 kg	35,770-36,850 kg
Bucket Capacity	2.66 m³	2.66 m³	2.66 m³
Fuel Efficiency	Up to 13% better than prior	Up to 5% better than -10	Same as -11
Machine Control	Optional grade guidance	Optional iMC 1.0	iMC 2.0 standard
Auto Idle Shutdown	No	Yes	Yes
Neutral Detection	No	Yes	Yes
Lift Mode	Yes (+6% lifting force)	Yes	Yes
KOMTRAX	Yes	Yes	Yes

Detailed Variant Descriptions:

1. PC360LC/NLC-10

The “dash 10” generation introduced significant fuel savings (up to 13%)
Features Komatsu’s CLSS hydraulics and SpaceCab™ safety design
Available in LC (Long Crawler) and NLC (Narrow Long Crawler) configurations
Emission standards: Tier 4 Interim / Stage IIIB
Now in product archive (discontinued but widely available used)

2. PC360LC/NLC-11

Current base model with EU Stage V / Tier 4 Final engine
Integrates SCR technology with AdBlue® additive for NOx reduction
5% fuel consumption reduction compared to -10 series
Auto idle shutdown and neutral detection system for additional fuel savings
Available in demolition and waste handling (WH) packages

3. PC360LCi-11 (iMC 2.0)

Intelligent Machine Control 2.0 with advanced automation features:
- Auto Tilt Control – Easier operation of tilting buckets on slope and ditch work
- Automatic Limit to Under-digging – Prevents digging below design surface
- Bucket Angle Hold – Automatically maintains bucket angle during grading passes
- Auto Grade Assist – Helps maintain grade without manual intervention
Updated iMC 2.0 monitor: 36% slimmer, 38% lighter than previous version
Improved touchscreen navigation and increased memory
Tilt Bucket Integration via IMU sensor for various bucket types
Smart Construction Remote subscription allows remote design file transfer

LC vs. NLC (Narrow Long Crawler) Undercarriage :

Consideration	LC (Long Crawler)	NLC (Narrow Long Crawler)
Stability	Maximum stability for heavy lifting	Good stability with narrower track
Transport Width	Standard width (~3,190 mm)	Narrower for transport compliance
Ground Pressure	Lower (better flotation)	Slightly higher
Best For	Quarries, heavy excavation	Road construction, transport-restricted sites

Specialized Packages:

Package	Key Features	Best For
WH (Waste Handling)	Auto reversing fan, engine pre-cleaner, wide core cooling, chassis seals, 9mm undercovers	Landfills, recycling centers, scrap yards
Demolition	Straight boom (12.9m height), heavy-duty guarding, reinforced linkage	Building demolition, high-reach work

Which Model Should You Choose?

Scenario	Recommended Model
Maximum productivity with automation	PC360LCi-11 (iMC 2.0)
Standard construction / earthmoving	PC360LC-11
Transport width restrictions	PC360NLC-11
Budget-conscious / used market	PC360-10
Landfill / waste management	PC360LC-11 WH
Building demolition	PC360LC-11 Demolition

Pro Tip: The iMC 2.0 models can replace both standard excavators and dozers on grading applications, allowing fleet optimization and equipment redeployment .
